Double Chamber Pulverizer 10 HP | Reindeer Machinery
Press 🌐 to select Language
Press [T] to read the text.
wait for 20 seconds.
Quick Specification
| Materials | wheat, maize, bajra, jowar, rice, pulses etc. |
| Output | ~100 kg/hr (depends on HP, material & mesh) |
| Power | 10 HP |
| Fineness (Mesh) | Upto 70 mesh |
| Body Options | CI (Cast Iron) + MS (Mild Steel) or SS304 Food Grade |
Before You Buy
See how this high-output pulverizer works in real production conditions.
Watch grinding performance, finish quality, and operator handling in detail.
Explore more machines in our Pulverizers range below.
Not sure which Machine you need?
Share material name + required kg/hr on WhatsApp — we’ll suggest the right model + HP recommendation.
187K+ Subscribers
500+ Google Reviews
Export to 30+ Countries
Warranty + Spares Support
AI Assistant (Contact Us Button) |
| MODEL | MSH10D |
|---|---|
| Production Capacity | ~100 Kg/Hr |
| Grinding Materials | wheat, maize, bajra, jowar, rice, pulses (as per model) (depends on HP, material & mesh) |
| Electric Motor | 10 HP Crompton Motor IE2 ISI |
| Motor Brand | CG - Crompton |
| Ele. Motor RPM | 1440 RPM |
| Phase | Three Phase |
| Voltage | 440V, 50Hz |
| Power Consumption | 7.5 kWh (7.5 Units/hr) |
| Mechanism RPM | ~3000 RPM |
| Chamber Size | 14" Diameter |
| Body Structure | MS + CI Body or CI, MS & SS304 Food Grade |
| Contact Parts | MS full Body or Full body SS304 Food Grade (on Demand) |
| Weight | 200 kg |
| Dimension (LxWxH) | 5' x 4' x 6' (feet) |
| Accessories | 2 Clothes (Anti-Vibration pad Extra) |
| Foundation Required | Yes or Anti-Vibration Pad |
Model Range
| SSH3 ~30 kg/hr | 3 HP Motor (Single / Three Phase) |
|---|---|
| SSH5 ~50 kg/hr | 5 HP Motor (Single / Three Phase) |
| MSH7.5D ~70 kg/hr | 7.5 HP Motor (Singe/ Three Phase) |
| MSH10D ~100 kg/hr | 10 HP Motor (Three Phase) |
| MSH15D ~150 kg/hr | 15 HP Motor (Three Phase) |
| MSH20DB ~180 kg/hr | 20 HP Motor (Three Phase) |
