Atta Chakki 10 HP for Commercial Use | Reindeer Machinery
Quick Specification
| Materials | wheat, maize, bajra, jowar, rice, pulses etc. |
| Output | ~100 kg/hr (depends on HP, material & mesh) |
| Power | 10 HP |
| Fineness (Mesh) | Upto 70 mesh |
| Body Options | CI (Cast Iron) + MS (Mild Steel) or SS304 Food Grade |
Before You Buy
The atta chakki is designed for high-output commercial flour grinding where consistency and durability matter. Watch the video below to understand build quality, working, and output range. Explore similar machines in our Commercial Atta Chakki Machines collection.
187K+ Subscribers
500+ Google Reviews
Export to 30+ Countries
Warranty + Spares Support
Not sure which Machine you need?
Share material name + required kg/hr on WhatsApp — we’ll suggest the right model + HP recommendation.
Atta Chakki
| MODEL | MSH10D |
|---|---|
| Production Capacity | ~100 Kg/Hr |
| Grinding Materials | wheat, maize, bajra, jowar, rice, pulses (as per model) (depends on HP, material & mesh) |
| Electric Motor | 10 HP Crompton Motor IE2 ISI |
| Motor Brand | CG - Crompton |
| Ele. Motor RPM | 1440 RPM |
| Phase | Three Phase |
| Voltage | 440V, 50Hz |
| Power Consumption | 7.5 kWh (7.5 Units/hr) |
| Mechanism RPM | ~3000 RPM |
| Chamber Size | 14" Diameter |
| Body Structure | MS + CI Body or CI, MS & SS304 Food Grade |
| Contact Parts | MS full Body or Full body SS304 Food Grade (on Demand) |
| Weight | 200 kg |
| Dimension (LxWxH) | 5' x 4' x 6' (feet) |
| Accessories | 2 Clothes (Anti-Vibration pad Extra) |
| Foundation Required | Yes or Anti-Vibration Pad |
Model Range
| SSH3 ~30 kg/hr | 3 HP Motor (Single / Three Phase) |
|---|---|
| SSH5 ~50 kg/hr | 5 HP Motor (Single / Three Phase) |
| MSH7.5D ~70 kg/hr | 7.5 HP Motor (Singe/ Three Phase) |
| MSH10D ~100 kg/hr | 10 HP Motor (Three Phase) |
| MSH15D ~150 kg/hr | 15 HP Motor (Three Phase) |
| MSH20DB ~180 kg/hr | 20 HP Motor (Three Phase) |
Not sure which Machine you need?
Share your material name + required kg/hr on WhatsApp — we’ll suggest the right model.
