Atta Mill 10 HP Heavy Duty | Reindeer Machinery
Quick Specification
| Materials | wheat, maize, bajra, jowar, rice, pulses etc. |
| Output | ~100 kg/hr (depends on HP, material & mesh) |
| Power | 10 HP |
| Fineness (Mesh) | Upto 70 mesh |
| Body Options | CI (Cast Iron) + MS (Mild Steel) or SS304 Food Grade |
Before You Buy
This heavy-duty Atta Mill is engineered for continuous commercial flour production with stable output and long service life. Watch the video to understand build quality, grinding performance, and installation details. Explore similar options in our Atta Mill Machines collection.
187K+ Subscribers
500+ Google Reviews
Export to 30+ Countries
Warranty + Spares Support
Not sure which Machine you need?
Share material name + required kg/hr on WhatsApp — we’ll suggest the right model + HP recommendation.
Atta Mill
| MODEL | MSH10D |
|---|---|
| Production Capacity | ~100 Kg/Hr |
| Grinding Materials | wheat, maize, bajra, jowar, rice, pulses (as per model) (depends on HP, material & mesh) |
| Electric Motor | 10 HP Crompton Motor IE2 ISI |
| Motor Brand | CG - Crompton |
| Ele. Motor RPM | 1440 RPM |
| Phase | Three Phase |
| Voltage | 440V, 50Hz |
| Power Consumption | 7.5 kWh (7.5 Units/hr) |
| Mechanism RPM | ~3000 RPM |
| Chamber Size | 14" Diameter |
| Body Structure | MS + CI Body or CI, MS & SS304 Food Grade |
| Contact Parts | MS full Body or Full body SS304 Food Grade (on Demand) |
| Weight | 200 kg |
| Dimension (LxWxH) | 5' x 4' x 6' (feet) |
| Accessories | 2 Clothes (Anti-Vibration pad Extra) |
| Foundation Required | Yes or Anti-Vibration Pad |
Model Range
| SSH3 ~30 kg/hr | 3 HP Motor (Single / Three Phase) |
|---|---|
| SSH5 ~50 kg/hr | 5 HP Motor (Single / Three Phase) |
| MSH7.5D ~70 kg/hr | 7.5 HP Motor (Singe/ Three Phase) |
| MSH10D ~100 kg/hr | 10 HP Motor (Three Phase) |
| MSH15D ~150 kg/hr | 15 HP Motor (Three Phase) |
| MSH20DB ~180 kg/hr | 20 HP Motor (Three Phase) |
